Description
F-Force Series range in size from 50 to 80 HP
Product Description:
F-Force series utilizes two of our largest chiller barrels, and it is used for large range cooling capacity applications such as big fish farms. This series utilizes two oversized high-capacity U-tube heat exchanger. It is compatible with both fresh and salt water, and it is for high flow rate applications.
Features:
- Cooling capacity range between 600,000-960,000 BTU/H
- Non-corrosive and non-contaminating extended dual high capacity titanium u-tube heat exchanger
- 3" to 6" flange water connections
- 1/2" OD titanium dry-well for temperature sensor
- The chiller barrel shell is CSA & NSF rated
- Salt and freshwater compatible
- Made in Canada
Contact us for more information.
|
Capacity Specification
|
|
Model
|
HP
|
Min/Max Flow Rate
|
Nominal BTU/H
|
Refrigeration Inlet/Outlet
|
Process Water In/Out
|
|
FF-DX-5000-4F
|
50 |
75/150 GPM
|
300,000
|
2 @ 2 ⅛"
|
4" Flange
|
|
FF-DX-6000-4F
|
60 |
75/150 GPM
|
360,000
|
2 @ 2 ⅛"
|
4" Flange
|
|
FF-DX-7000-4F
|
70 |
75/150 GPM
|
420,000
|
2 @ 2 ⅛"
|
4" Flange
|
|
FF-DX-8000-4F
|
80 |
125/250
|
480,000
|
2 @ 2 ⅛"
|
4" Flange
|
|
Dimensions
|
| Model | A | B | C | D |
| FF-DX-5000-4F | 138" | 127" | 28 ¾" | 37 ½" |
| FF-DX-6000-4F | 138" | 127" | 28 ¾" | 37 ½" |
| FF-DX-7000-4F | 138" | 127" | 28 ¾" | 37 ½" |
| FF-DX-8000-4F | 138" | 127" | 28 ¾" | 37 ½" |
- Dimensions may vary, if size is critical, please contact Marine Build to discuss options
