Description
A-Force Series range in size from 1/4 to 1 HP
Product Description:
A-Force series chiller barrels are compact in size and is used for small range cooling capacity applications such as fish tanks, and smaller live-seafood systems. The chiller barrel is not only salt water compatible, it can also be used for a large range of different type of fluids.
Features:
- Cooling capacity range between 3,000-12,000 BTU/H
- Non-corrosive and non-contaminating titanium helical coil heat exchanger
- 1” union water inlet and outlet
- 1/2" OD titanium dry-well for temperature sensor
- The chiller barrel shell is CSA & NSF rated
- Salt and freshwater compatible
- Made in Canada
Contact us for more information.
| Capacity Specification |
| Model | HP |
Nominal BTU/H |
Min/Max Flow Rate |
Process Water In/Out |
Refrigeration Inlet/Outlet |
| AF-DX-0025-1U | 1/4 | 3,000 | 10/40 GPM | 1" FNPT | ⅜ " / ⅜ " |
| AF-DX-0033-1U | 1/3 | 4,000 | 10/40 GPM | 1" FNPT | ⅜ " / ⅜ " |
| AF-DX-0050-1U | 1/2 | 6,000 | 10/40 GPM | 1" FNPT | ⅜ " / ⅜ " |
| AF-DX-0075-1U | 3/4 | 9,500 | 10/40 GPM | 1" FNPT | ½ " / ⅝ " |
| AF-DX-0100-1U | 1 | 12,000 | 10/40 GPM | 1" FNPT | ½ " / ⅝ " |
| Dimensions |
|
Model
|
A
|
B
|
C
|
D
|
| AF-DX-0025-1U | 13 ½" |
7 ½"
|
7 ¼"
|
10"
|
|
AF-DX-0033-1U |
13 ½" |
7 ½"
|
7 ¼" |
10" |
|
AF-DX-0050-1U |
15 ½" |
9 ½"
|
7 ¼" | 10" |
| AF-DX-0075-1U | 19 ½" |
13 ½"
|
7 ¼" |
10"
|
| AF-DX-0100-1U |
23 ½"
|
17 ½"
|
7 ¼"
|
10"
|
- Dimensions may vary, if size is critical, please contact Marine Build to discuss options
Option: Available in a pre-assembled package
Pre-assembled package Includes:
- Electronic controller
- All required refirgeration components
- Marine-grade aluminum mounting frame
- Single point electrical connection
- Saftey flow switch (Optional)
Review A-Force Package Specification PDF for further details or go to Chiller Barrel Package page.
