KiteCore 1-1/2 HP to 15 HP
KiteCore 1-1/2 HP to 15 HP
Roll over image to zoom in Click on image to zoom
KiteCore 1-1/2 HP to 15 HPKiteCore 1-1/2 HP to 15 HP

KiteCore 1-1/2 HP to 15 HP

Marine Build

Please contact us for a quote at sales@marinebuild.com

Description

KiteCore chillers range in size from 1-1/2 HP to 15 HP

-Formly known as Ti-Chaf



Product Description:







The KiteCore series is powered by Canadian-made commercial-grade condensing units and utilizes top-of-the-line refrigeration equipment. This series is for medium to large-range applications such as seafood processing systems to fish farms. The KiteCore is customizable to fit any type of scenario such as extreme conditions or precise temperature control.

Features:

  • Utilizes Canadian made commercial condensing units to handle the most rugged conditions
  • Temperature range capability is between 40ºF-80ºF (4.5ºC–27ºC)
  • Non-corrosive and non-contaminating high efficiency titanium coil heat exchanger
  • Mounted on a welded marine grade aluminum frame
  • 2" to 4" union or flange water connections
  • Includes safety flow switch, dual pressure safety switch, and compressor short cycling time delay
  • Includes weather resistant NEMA 4 electronic controller
  • UL and/or CSA approved condensing unit and components
  • Salt or freshwater compatible
  • Avaible model for indoors or outdoors
  • Made in Canada
 Capacity Specifications
Model Nominal HP BTU/H KW

  Temp Range     [ °F]

 Min/Max Flow [GPM]
KC-0150-B15U 1.5 18,300 5.36 40-80 50-100
KC-0200-B15U 2
 25,100 7.36 40-80 50-100
KC-0300-B15U 3 37,800 11.08 40-80 50-100
KC-0400-B15U 4
 46,900 13.75 40-80 50-100
KC-0500-B15U 5
 60,500 17.73 40-80 50-100
KC-0600-C15U 6
 72,200 21.16 40-80 50-100
KC-0650-C15U 6.5 78,200 22.92 40-80 60-100
KC-0800-C15U 8 97,400 27.96 40-80

60-100

120-200
KC-1000-C15U 10 128,000 37.51 40-80

75-150

150-300
KC-1500-C15U 15 182,000 53.34 40-80

75-150

150-300

  • Nomical Capacity is based on an ambient temperature of 90°F and an evaporate temperature of 45°F.
  • Flow rate requirements are relative to water temperature. As a rule of thumb, colder water requires higher flow.
  • Ensure the recommended water flow rate found on the chart is followed or the titanium coil may freeze and damage the chiller.



 Electrical and Physical Specifications
Model Electrical Ratings [V/Ph/Hz] MCA

 Fuse [Amps]

 Water Connections Dimensions [LxWxH]
KC-0150-B15U 208-240/3/60
 12.13 20
 2" Union w/ FNPT N/A
KC-0200-B15U 208-240/3/60 12 20 2" Union w/ FNPT N/A
KC-0300-B15U 208-240/3/60 19.25 30 2" Union w/ FNPT N/A
KC-0400-B15U 208-240/3/60 23.25 35 2" Union w/ FNPT N/A
KC-0500-B15U 208-240/3/60 27.25 45 2" Union w/ FNPT N/A
KC-0600-C15U  208-240/3/60 27.25 45 2" Union w/ FNPT N/A
KC-0650-C15U 208-240/3/60 34.93 50 2" Union w/ FNPT N/A
KC-0800-C15U 208-240/3/60 42.93 70 2" Union w/ FNPT N/A
KC-1000- 208-240/3/60 53.43 90 N/A N/A
KC-1500- 208-240/3/60 74.68 125 N/A N/A



  • Specifications subject to change without notice, and dimensions may vary.
  • Contact Marine Build for different power requirements.
