Description
Chiller Barrel Packages range in size from 1/4 to 10 HP
Product Description:
Chiller barrel packages has pre-installed refrigeration and electrical components and is designed for ease of installation. The available models range from small to large cooling capacity. If a remote chiller barrel is required, the chiller barrel package is your solution.
Features:
- Cooling capacity range between 3,000-120,000 BTU/H
- Non-corrosive and non-contaminating high efficiency titanium coil heat exchanger
- Mounted on a wall and floor mount combination welded marine grade aluminum frame
- 2” union water inlet and outlet
- LCD temperature readout in Fahrenheit or Celsius with programmable time delay
- Includes safety flow switch, thermostatic expansion valve, 120V or 240V solenoid, filter drier, & sight glass
- 1/2" OD titanium dry-well for temperature sensor
- Includes
- The chiller barrel shell is CSA & NSF rated
- Salt and freshwater compatible
- Made in Canada
Contact Marine Build to indicate 120V or 240V selection.
Condensing units sold separately.
| Model Description | HP | Nominal BTUH |
| AFP-DX is our heat exchanger package line that ranges from 1/4 HP to 1 HP. Review attached pdf for further deatials : A-Force package | 1/4 - 1 | 3,000 - 12,000 |
| BFP-DX is our heat exchanger package line that ranges from 1½ HP to 5 HP. Review attached pdf for further deatials : B-Force package | 1½ - 5 | 18,000 - 60,000 |
| CFP-DX is our heat exchanger package line that ranges from 6 HP to 10 HP. Review attached pdf for further deatials : C-Force package | 6-10 | 72,000 - 120,000 |
- Dimension may vary, if size is critical, please contact Marine Build to discuss options
